NC1300F 3-Axis Gun Drilling Machine

NC1300F 3-Axis Gun Drilling Machine

Description:

NC1300F 3-axis gun drilling machine is widely used to process waterway hole, center hole, hot runner hole, hydraulic valve, distributor and heat exchanger plate, etc. Its depth of drill hole is 1300mm. With high precision and high productivity, NC1300F 3-axis gun drilling machine is an ideal choice.

Features:

1. With three spindles, the machine ensures high efficiency and stability of processing.
2. NC1300F 3-axis gun drilling machine adopts imported linear guide rail and ball screw to ensure the high precision
3. Pump system with large capacity is provided to cover the wide range of machine.
4. NC1300F 3-axis gun drilling machine takes operator’s safety, machine aesthetics, convenient operation into consideration.

Parameter:

Type NC1300F 3-axis gun drilling machine
Bore of drill hole φ3-30mm
Maximum depth of one-off drill hole 1300mm
Dimension of work platform 1000x1700mm
X axis stroke 1600mm
Y axis stroke 1000mm
Z axis stroke 1350mm
Rapid feeding 4000mm/min
Maximum rotary sped of spindle 6000rpm
Spindle power 7.5kw
XYZ servo motor power 3kw/3kw/1.5kw
Pressure of cutting oil pump 100kg/cm2
Oil pump capacity of oil hydraulic pump 8-42L/min
Capacity of cutting oil tank 400L
Load weight of work platform 8000kg
Net weight of equipment 12000kg
External size of machine tool 5400x4800x2900mm
Total power 35kw
Numerical control system MITSUBISHI

Accessories for NC1300F 3-axis gun drilling machine include standard fittings and available accessories. Standard accessories cover transformer, main shaft etc. If you need more information, please refer toNCS Series_pdf.
